ASME / ANSI B16.9 Seamless Buttweld Concentric Reducer, High-Quality Buttweld Concentric Reducer Exporters in India, Industrial Welded Concentric Reducer, ANSI/ASME B16.9 Stainless Steel Concentric Reducer also available in Duplex Steel, Alloy Steel, Hastelloy, Monel, Carbon Steel, Inconel, Titanium, Incoloy, Super Duplex, Alloy 20, 254 SMO, Copper Nickel, High & Low-Temperature Steel, Mild Steel Suppliers in South Africa, Malaysia, Singapore, UK, Philippines, Australia and UAE.
Masiva Solutions is a leading Manufacturer, Supplier, and Exporter of Concentric Reducer Buttweld Pipe Fittings that are being designed as per the national and international standard quality of raw materials and thus ensuring their durability and top quality . the main purpose of SS Concentric Reducer is to reduce down the curvature from a better to the lesser size of the pipe, which actually outcomes during a greater than before flow pressure.
A Buttweld Concentric Reducer is additionally called welded concentric coupling. It allows connecting an outsized pipe to a smaller pipe by means of welding. The Buttweld Concentric Reducer is manufactured in order that both inlet and outlet ends are on a standard centerline. The Concentric Reducer Pipe Fittings are easier and less expensive to supply but don’t allow quite an equivalent versatility because of the eccentric reducer.
A Concentric Reducer is used to affix pipe sections or tube sections on an equivalent axis. The concentric reducer is cone-shaped and is used when there’s a shift in diameter between pipes. This pipe reducer is also used when there’s one diameter change or multiple diameter changes. concentric reducers have a standard centerline. Concentric reducers are useful when cavitation is present.
ANSI B16.9 Buttweld Concentric Reducer Specifications
- Type Industrial Buttweld Concentric Reducer
- Size Seamless Reducer ( 1/2″～24″), ERW / Welded / Fabricated Reducer (1/2″～48″)
- Standard ANSI B16.9, ANSI B16.28, MSS-SP-43
- Class 150 LBS, 300 LBS, 600 LBS, 900 LBS, 1500 LBS, 2500 LBS, DIN Standard ND-6,10, 16, 25, 40
- Thickness SCH10, SCH20, SCH30, STD SCH40, SCH60, XS, SCH 80, SCH 100, SCH 120, SCH 140, SCH 160, XXS available with NACE MR 01-75.
- DIN DIN2527, DIN2566, DIN2573, DIN2576, DIN2641, DIN2642, DIN2655, DIN2656, DIN2627, DIN2628, DIN2629, DIN 2631, DIN2632, DIN2633, DIN2634, DIN2635, DIN2636, DIN2637, DIN2638, DIN2673
- BS BS4504 , BS4504, BS1560, BS10
- Specialize As per drawing
- Coating / Surface Treatment Anti-rust Paint, Oil Black Paint, Yellow Transparent, Zinc Plated, Cold and Hot Dip Galvanized
- Connection Type Buttwelding Fittings
- Dimensions ANSI B16.9, ANSI B16.28, MSS-SP-43
- Usage/Applications Oil Field, Offshore, Water System, Shipbuilding, Natural Gas, Electric Power, Pipe Projects etc.
Buttweld Concentric Reducer Dimensions
ASME B16.9 Buttweld Reducers Dimensions
Manufacturing Standards of Buttweld Concentric Reducer
| ASME Standard |
ASME/ANSI B16.9, ASME/ANSI B16.28, MSS-SP-43 |
| DIN Standard |
DIN28011, DIN2617, DIN2616, DIN2615, DIN2605 |
| EN Standard |
EN10253-2, EN10253-1 |
| ASME B16.25 |
Buttwelding Ends |
| ASME B16.9 |
Factory-Made Wrought Fittings Buttwelding |
| ASME B16.28 |
Wrought Steel Concentric Reducer |
| ASTM A403 – ASME SA403 |
Standard Specification for Wrought Austenitic Stainless Steel Piping Fitting |
| MSS SP-43 |
Wrought & Fabricated Butt-Welding Fitting for Low Pressure, Corrosion Resistant Applications |
ASME / ANSI B16.9 Buttweld Concentric Reducer Material & Grades
Stainless Steel Buttweld Concentric Reducer :
ASTM A403 WP316/316L, ASTM A403 SA / A 774 WP-S, WP-W, WP-WX 304/304L, ASTM A182 F316L, 304L, DIN 1.4301, DIN1.4306, DIN 1.4401, DIN 1.4404
Duplex & Super Duplex Steel Concentric Reducer :
ASTM A 815, ASME SA 815 UNS NO S31803, S32205. UNS S32750, S32950. Werkstoff No. 1.4462
Carbon Steel Buttweld Concentric Reducer :
ASTM A234, ASME SA234 WPB , WPBW, WPHY 42, WPHY 46, WPHY 52, WPH 60, WPHY 65 & WPHY 70.
Low Temperature Carbon Steel Buttweld Concentric Reducer : ASTM A420 WPL3, A420 WPL6
Alloy Steel Buttweld Concentric Reducer :
ASTM / ASME A/SA 234 Gr. WP 1, WP 5, WP 9, WP 11, WP 12, WP 22, WP 91
Nickel Alloy Buttweld Concentric Reducer :
ASTM B336, ASME SB336, Nickel 200 (UNS No. No2200), Nickel 201 (UNS No. N02201), Monel 400 (UNS No. N04400), Monel 500 (UNS No. N05500), Inconel 800 (UNS No. N08800), Inconel 825 (UNS No. N08825), Inconel 600 (UNS No. N06600), Inconel 625 (UNS No. N06625), Inconel 601 (UNS No. N06601), Hastelloy C 276 (UNS No. N10276), Alloy 20 (UNS No. N08020), Titanium (Grade I & II), Cupro-Nickel 70/30, CuNi10Fe1Mn, CuNi30Mn1Fe.
ASME B16.9 Buttweld Concentric Reducer Weight Chart in KG
| NPS |
LBS |
KG |
| 4-3 |
3.38 |
1.53 |
| 4-2.1/2 |
3.25 |
1.47 |
| 4-2 |
3 |
1.36 |
| 3.1/2-2.1/2 |
2.88 |
1.31 |
| 3.1/2-2 |
2.75 |
1.25 |
| 3.1/2-1.1/2 |
2.5 |
1.13 |
| 3.1/2-1.1/4 |
2.4 |
1.09 |
| 4-3.1/2 |
3.5 |
1.59 |
| 4-1.1/2 |
2.88 |
1.31 |
| 5-4 |
6 |
2.72 |
| 5-3.1/2 |
5.75 |
2.61 |
| 5-3 |
5.5 |
2.49 |
| 5-2.1/2 |
5.25 |
2.38 |
| 5-2 |
5 |
2.27 |
| 6-5 |
8.5 |
3.86 |
| 6-4 |
8.25 |
3.74 |
| 6-3.1/2 |
8.25 |
3.74 |
| 6-3 |
8 |
3.63 |
| 6-2.1/2 |
7.25 |
3.29 |
| 8-6 |
13.2 |
5.99 |
| 8-5 |
12 |
5.44 |
| 8-4 |
11 |
4.99 |
| 8-3.1/2 |
11 |
4.99 |
| 10-8 |
22 |
9.98 |
| 10-6 |
21.5 |
9.75 |
| 10-5 |
21 |
9.53 |
| 10-4 |
20 |
9.07 |
| 12-10 |
34 |
15.42 |
| 12-8 |
32 |
14.51 |
| 12-6 |
31 |
14.06 |
| 12-5 |
30 |
13.61 |
| 14-12 |
60 |
27.22 |
| 14-10 |
59.2 |
26.85 |
| 14-8 |
58.5 |
26.54 |
| 14-6 |
58 |
26.31 |
| 16-14 |
71 |
32.21 |
| 16-12 |
70 |
31.75 |
| 16-10 |
69.5 |
31.52 |
| 16-8 |
68.5 |
31.07 |
| 16-6 |
– |
– |
| 18-16 |
85 |
38.56 |
| 18-14 |
84 |
38.1 |
| 3/4-1/2 |
0.17 |
0.08 |
| 3/4-3/8 |
0.15 |
0.07 |
| 1-3/4 |
0.4 |
0.18 |
| 1-1/2 |
0.4 |
0.18 |
| 1.1/4-1 |
0.5 |
0.23 |
| 1.1/4-3/4 |
0.4 |
0.18 |
| 1.1/4-1/2 |
0.4 |
0.18 |
| 1.1/2-1.1/4 |
0.7 |
0.32 |
| 1.1/2-1 |
0.62 |
0.28 |
| 1.1/2-3/4 |
0.54 |
0.24 |
| 1.1/2-1/2 |
0.5 |
0.23 |
| 2-1.1/2 |
0.9 |
0.41 |
| 2-1.1/4 |
0.84 |
0.38 |
| 2-1 |
0.76 |
0.34 |
| 2-3/4 |
0.7 |
0.32 |
| 2.1/2-2 |
1.5 |
0.68 |
| 2.1/2-1.1/2 |
1.38 |
0.63 |
| 2.1/2-1.1/4 |
1.25 |
0.57 |
| 2.1/2-1 |
1.25 |
0.57 |
| 3-2.1/2 |
2 |
0.91 |
| 3-2 |
1.8 |
0.82 |
| 3-1.1/2 |
1.7 |
0.77 |
| 3-1.1/4 |
1.6 |
0.73 |
| 3.1/2-3 |
3.15 |
1.43 |
| 18-12 |
83 |
37.65 |
| 18-10 |
82 |
37.19 |
| 18-8 |
– |
– |
| 20-18 |
125 |
56.7 |
| 20-16 |
124 |
56.25 |
| 20-14 |
122 |
55.34 |
| 20-12 |
120 |
54.43 |
| 20-10 |
– |
– |
| 20-8 |
– |
– |
| 22-20 |
142 |
64.41 |
| 22-18 |
138 |
62.6 |
| 22-16 |
131 |
59.42 |
| 22-14 |
123 |
55.79 |
| 22-12 |
– |
– |
| 22-10 |
– |
– |
| 24-22 |
– |
– |
| 24-20 |
150 |
68.04 |
| 24-18 |
148 |
67.13 |
| 24-16 |
145 |
65.77 |
| 24-14 |
– |
– |
| 30-26 |
232 |
105.23 |
| 30-24 |
224 |
101.6 |
| 30-22 |
220 |
99.79 |
| 30-20 |
220 |
99.79 |
| 24-12 |
– |
– |
| 24-10 |
– |
– |
| 26-24 |
207 |
93.89 |
| 26-22 |
200 |
90.72 |
| 26-20 |
190 |
86.18 |
| 26-18 |
182 |
82.55 |
| 26-16 |
– |
– |
| 26-14 |
– |
– |
| 26-12 |
– |
– |
| 28-26 |
224 |
101.6 |
| 28-24 |
216 |
97.98 |
| 28-22 |
210 |
95.25 |
| 28-20 |
199 |
90.26 |
| 30-28 |
241 |
109.32 |
ASME B16.9 Buttweld Concentric Reducer Manufacturing Process
The most appropriate Manufacturing Process for every product are going to be decided considerately of its material, sizes, shape, use, standards, and special properties. There are various Pipe Fittings Manufacturing Processes that want to manufacture Stainless Steel Concentric Reducer and other pipe Fittings.
One of the foremost common Pipe Fittings Manufacturing Process of Carbon Steel Buttweld Concentric Reducer from the pipe is a mandrel method which is quite hot forming methods. During this method, The pipe is cut into pieces and push with the assistance of a hydraulic pump. The heating coil heats the pipe and, it’s pushed over a die called, “mandrel” which allows the pipe to expand and bend simultaneously. This method is often wont to manufacture a good range of the diameter of Alloy Steel Concentric Reducer.
Buttweld Concentric Reducer are manufactured from Seamless Pipe and from Welded Pipe with filler materials. Large diameter fittings are manufactured from Plate. We’ve only covered the renowned Pipe Fittings Manufacturing Process here. There are many other methods that used to support the necessities.
Dimensional Tolerances of Buttweld Concentric Reducer as per ASME B16.9
| Nominal Pipe Size |
1/2 to 2½ |
3 to 3½ |
4 |
5 to 8 |
Outside Diameter
at Bevel (D) |
+ 1.6
– 0.8 |
1.6 |
1.6 |
+ 2.4
– 1.6 |
| Inside Diameter at End |
0.8 |
1.6 |
1.6 |
1.6 |
| Center to End LR (A/B) |
2 |
2 |
2 |
2 |
| Center to End 3D (A/B) |
3 |
3 |
3 |
3 |
| Nominal Pipe Size |
10 to 18 |
20 to 24 |
26 to 30 |
32 to 48 |
Outside Diameter
at Bevel (D) |
+ 4
– 3.2 |
+ 6.4
– 4.8 |
+ 6.4
– 4.8 |
+ 6.4
– 4.8 |
| Inside Diameter at End |
3.2 |
4.8 |
+ 6.4
– 4.8 |
+ 6.4
– 4.8 |
| Center to End LR (A/B) |
2 |
2 |
3 |
5 |
| Center to End 3D (A/B) |
3 |
3 |
6 |
6 |
| Wall Thickness (t) |
Not less than 87.5% of Nominal Wall Thickness |
Available Types of ASME B16.9 Buttweld Concentric Reducer
| ANSI B16.9 Buttweld Concentric Reducer |
ASME B16.28 Buttweld Concentric Pipe Reducer |
| Welded Butt weld Concentric Reducer |
Seamless Butt weld Concentric Reducer |
| Buttweld Concentric Reducer |
Butt Weld Pipe Reducers |
| ASME B16.9 Butt weld Concentric Reducer |
Steel Reducer Pipe Fittings |
| Stainless Steel Concentric Reducer |
SS Concentric Reducers |
| Carbon Steel Concentric Reducer |
High Quality Concentric Reducer |
| ASTM A403 Stainless Steel Concentric Reducers |
Duplex Steel Buttweld Concentric Reducer |
| Super Duplex Steel Buttweld Concentric Reducer |
Copper Nickel Concentric Reducer |
| High Nickel Alloy Concentric Reducer |
Hastelloy Concentric Reducer |
| Titanium Buttweld Concentric Reducer |
Inconel Butt weld Concentric Reducer |
Butt weld Concentric Reducer Application Industries
- Refineries
- Food Processing & Dairy
- Oil and Gas Industry
- Off-Shore Oil Drilling Companies
- Pharmaceutical Equipment
- Pulp & Paper Industry
- Power Generation
- Specialty Chemicals
- Sea Water Equipment
- Gas Processing
- Chemical Equipment
- Heat Exchangers
- Petrochemicals
- Pharmaceuticals
- Condensers
ASME B16.9 Concentric Reducer Inspection
All Buttweld Concentric Reducer are inspected and tested in accordance with the relevant product standard (eg. ASME/ANSI B16.9, ANSI B16.28, MSS-SP-43) or code and as stated in the Purchase requisition. Pressure testing or Hydro-testing of Stainless Steel Concentric Reducer where required by the standard shall be performed using water having less than 30ppm of chlorides. All welds in welded buttweld pipe fittings shall be 100% radiographed in accordance with the individual ASTM Standard. In lieu of radiography, Ultrasonic examination is not allowed. Examinations and/or tests may be reviewed and / or witnessed by the contractor or their authorized third party inspector at our facility. We are responsible for informing the contractor about the availability of goods for inspection and testing. Inspection is performed as per “Vendor Quality Requirement form” attached with the Inquiry / Purchase requisition. As a manufacturer, we submit the certificate of conformity of the material duly certified by inspector.
Buttweld Concentric Reducer Packing & Forwarding
Seamless Concentric Reducer are packed ready for export in a manner which allows easy handling and prevents damage. We submit our standard packing procedure to purchaser for approval. Open ends of Buttweld Concentric Reducer Pipe Fittings are supplied with heavy duty plastic protective plugs or caps. For bevelled ends, we insure that caps can protect the full area of the bevel. All material up to 6” in sizes shall be supplied in wooden boxes or cartons and as appropriate and adequately strapped. Buttweld Concentric Reducer Fittings over 6” shall be supplied on wooden pallets with metal straps. Also, the pallets shall be shrink wrapped. All shipping documentation is provided for seamless delivery from mill to purchaser.
