Half Coupling

Refer Stainless Steel Threaded Half Coupling Dimensions And ANSI B16.11 Screwed Half Coupling 1/2 6000# A105 Specification List.

ASME B16.11 Threaded Half Coupling

Stainless Steel Threaded Half Coupling

Carbon Steel Threaded Coupling



Table of contents

• What Is A Threaded Coupling?
• What Is The Pressure Rating Of ASME B16.11 Half Coupling?
• What Is A Half Coupling Used For?
• Difference Between Half Coupling And Full Coupling?
• Stainless Steel Threaded Half Coupling Dimensions
• Class 150 Half Coupling Dimensions
• ASME B16.11 Half Coupling Threaded - Class 3000
• Threaded Half Coupling 1/2 6000# A105 Dimensions
• Standard Specification Of Stainless Steel Threaded Half Coupling
• Threaded Half Coupling Price List
• Female & Male Half Coupling Size Chart
• Bspp Half Coupling Weight Chart According to ASME B16.11
• Threaded Joint Coupling Pressure Ratings
• Carbon Steel Half Coupling Tolerance Formula
• Frequently Used ASME B16.11 Threaded Half Coupling Types

Forged Steel Threaded Half Coupling

Threaded Half Coupling 1/2 6000# A105

ANSI B16.11 Screwed Half Coupling







What Is A Threaded Coupling?

The threaded pipe half coupling is a short length of pipe used to connect two pieces of pipe without the need for much space. A two inch threaded half coupling can have either male threads at one end or female threads and no thread on the other end. The ASME B16.11 half coupling threaded - class 3000 has 3000lb pressure containment and range from NPS1/2 to NPS4. The ASME B16.11 half coupling threaded dimensions include the bore diameter, wall thickness and the length of the coupling. The one inch 1 threaded half coupling can be used with a one inch piping. The different ASME B16.11 coupling allow for application in different projects.



What Is The Pressure Rating Of ASME B16.11 Half Coupling?

There are different standards and pressure classes to specify; for example the threaded half coupling 1/2 6000# a105 is a ½ inch 6000 class and is made up of a105 alloy. The threaded half coupling 3000 is made to handle pressures up to 3000 lbs. The threaded half coupling size is also involved in the pressure specifications. The wall thickness of the threaded half coupling stainless steel dimensions directly corresponds to the pressure containment. The sizes can vary from ½ inches such as in the threaded half coupling 1/2 up to 48 inches depending on the standards.



What Is A Half Coupling Used For?

The ASME B16.11 coupling threaded is used with a welding or without a welding. The materials range from stainless steel in ASME B16.11 half coupling threaded to alloys, brass and copper depending on the need of half coupling ASME B16.11 in specific applications. If the ASME B16.11 half coupling dimensions include different threads at each ends, it can be used as an adapter. The 1/2 threaded half coupling is used in low pressure applications, usually domestic. And the ASME B16.11 half coupling threaded vary according to applications such as the domestic water piping, gas, sea water and other industries. The main difference of half coupling and full coupling is that the half coupling only has threads at one end and the full coupling has threads at both ends.



Difference Between Half Coupling And Full Coupling

• The threaded half couplingdiffer and depend on the piping it is used in. The stainless steel threaded half coupling is the most used one in terms of the composition material.
• The threaded full couplingis a pipe fitting of short length that has two pipes joined together by threads at both ends.



ASME B16.11 Threaded Half Coupling Weight Chart, EIL Approved Carbon Steel Screwed Half Couplings Manufacturer In India.

Stainless Steel Threaded Half Coupling Dimensions



Class 150 Half Coupling Dimensions



ASME B16.11 Half Coupling Threaded - Class 3000

Normal Pipe Sizes (NPS)	End to End	(O.D.) Outside Diameter	Minimum Length of Thread
	A	D	B	J
1/2	48	28	10.9	13.6
3/4	51	35	12.7	13.9
1	60	44	14.7	17.3
1.1/4	67	57	17	18
1.1/2	79	64	17.8	18.4
2	86	76	19	19.2
2.1/2	92	92	23.6	28.9
3	108	108	25.9	30.5
4	121	140	27.7	33



Threaded Half Coupling 1/2 6000# A105 Dimensions

NPS (Normal Pipe Sizes)	End to End	O.D. (Outside Diameter)	Minimum Length of Thread
	A	D	B	J
1/2	48	38	10.9	13.6
3/4	51	44	12.7	13.9
1	60	57	14.7	17.3
1.1/4	67	64	17	18
1.1/2	79	76	17.8	18.4
2	86	92	19	19.2
2.1/2	92	108	23.6	28.9
3	108	127	25.9	30.5
4	121	159	27.7	33



ANSI B16.11 High Pressure Threaded Half Coupling Fittings Size Chart And Largest 1/2 Npt 3000# Half Couplings Supplier In Mumbai, India.

Standard Specification Of Stainless Steel Threaded Half Coupling

Specification :	ASME B16.11 Half Coupling
Pressure Rating	Threaded Fittings = Class 2000, Class 3000, Class 6000
Type Of Pipe systems	45 Deg Elbow, Equal tee, Full Coupling, Reducing Tee, 90 Deg Elbow, Half Coupling, Street Elbow, Bull Plug, Boss, Union (Male/Female), Lateral Outlet, 45 Lateral Tee, Equal Cross, Pipe Cap, Branch Outlets, Swage Nipple.
Material	Stainless Steel (ASTM-182) Carbon Steel (ASTM-105) Alloy Steel (ASTM-182) Low Alloy Steel (ASTM-350) Duplex Steel Cooper Nickel
Standards	ASME B16.11 (American Standard), Bs3799, MSS SP 79, JIS B2302, MSS-SP-97 (Threadolet), MSS-SP-83 (Union), ASME B36.19 (Nipple)
Types Of Thread	NPT, BSPP, BSPT, PF, PT, MPT
Applications	Oil and Gas Chemical Power station Water Pipeline Noncritical Applications Fire Protection
Advantages	Simple Usage Easy installation Economic as cheaper
Size	Threaded Fittings = ½” – 4”
Thread Connections	ASME B16.11 (Socket Welding and Threaded), MSS-SP-83 (Class Unions), ASME B16.3 (Malleable Iron Fittings), ASME B16.4 ( Gray Iron Fittings), ASME B16.39 (Malleable Iron Unions), ASME B16.34 (Valves — Flanged), ASME B16.39 (Malleable Iron Pipe Unions, 150#, 250#, Or 300#).



BSPP Forged Steel Screwed Half Coupling Pressure Rating, Contact For Best Copper/ Aluminum/ Brass Threaded Joint Couplings At Low-price.



Threaded Half Coupling Price List

Size	Class	Material	Price In US ($)
1/2 NPS	Class 3000	ASTM A105	$3.00
2 NPS	Class 3000,	ASTM A105	$15.6
1 NPS	Class 3000	ASTM A105	$7.3

Buy Now

Please note this is an approx Price of ASME B16.11 Threaded Coupling in India. For final Stainless Steel Threaded Coupling Price List Please Call on +91 - 22 - 67437342 or drop an Email to info@rajtilakmetal.com.





Female & Male Half Coupling Size Chart

Description	Class
	Class 2000	Class 3000	Class 6000
Coupling Half-Coupling	1/2 – 4	1/2 – 2	1/2 – 2
	1/2 – 4	1/2 – 2	1/2 – 2
	1/2 – 4	1/2 – 2	1/2 – 2
Normal Pipe Wall	SCH 80 / XS	SCH 160	XXS



NPS	End To End		Minimum Length Of  Thread		O.D.
Inches	ASME B16.11 Full Coupling	ASME B16.11 Half Coupling			Class 3000	Class 6000
	A	A/2	B	C	D	D
1/8	32	A/2	6.7	6.4	16	22
1/4	35	A/2	10.2	8.1	19	25
3/8	38	A/2	10.4	9.1	22	32
1/2	48	A/2	13.6	10.9	28	38
3/4	51	A/2	13.9	12.7	35	44
1	60	A/2	17.3	14.7	44	57
1 1/4	67	A/2	18	17	57	64
1 1/2	79	A/2	18.4	17.8	64	76
2	86	A/2	19.2	19	76	92
2 1/2	92	A/2	28.9	23.6	92	108
3	108	A/2	30.5	25.9	108	127
4	121	A/2	33	27.7	140	159



Looking To Buy Class 6000 Male/ Female Threaded Coupling Contact Rajtilak Metal, Specialise In Distributing Of ASME B16.11 Half Coupling Threaded - Class 3000.



Bspp Half Coupling Weight Chart According to ASME B16.11



Threaded Joint Coupling Pressure Ratings

ASME B16.11 Half Coupling Temperature		Class
		150	300
			1/4 – 1 inch.	1 1/4 – 2 inch.	2 1/2 – 3 inch.
(oF)	(oC)
-20 to 150	-29 to 66	300	2000	1500	1000
200	93	265	1785	1350	910
250	121	225	1575	1200	825
300	149	185	1360	1050	735
350	177	150	1150	900	650
400	204	–	935	750	560
450	232	–	725	600	475
500	260	–	510	450	385
550	288	–	300	300	300



Carbon Steel Half Coupling Tolerance Formula

ANSI B16.11 American Standard Dimensional Tolerances
"A" - Threaded Center To Bottom	For Size 1/8" And 1/4"	± 0.03"
	3/8", 1/2" And 3/4"	± 0.06"
	1", 1-1/4", 1-1/2" And 2"	± 0.08"
	2-1/2", 3", And 4"	± 0.10"
"B" - Threaded Bore Diameter	For Size 1-1/2" And Smaller	+ 0.020" - 0.000"
	2", 2-1/2", 3" And 4"	+ 0.025" - 0.000"
"C" - Threaded Wall Thick.	Min. = 1.09 T (But Not Less Than 5/32") T = Wall Thickness Of Nominal Pipe Sizes
"D" - Bore Diameter Of Pipe Fitting	For Size 2" And Smaller	± 0.030"
	2-1/2", 3" And 4"	± 0.060"
"E" - Threadeds- Bottom To Bottom - Full Couplings	For Size 1/8" And 1/4"	± 0.06"
	3/8", 1/2" And 3/4"	± 0.12"
	1", 1-1/4", 1-1/2" And 2"	± 0.16"
	2-1/2", 3", And 4"	± 0.20"
"F" - Bottom Of Threaded To Opposite Face - ANSI B16.11 Half Couplings	For Size 1/8" And 1/4"	± 0.03"
	3/8", 1/2" And 3/4"	± 0.06"
	1", 1-1/4", 1-1/2" And 2"	± 0.08"
	2-1/2", 3", And 4"	± 0.10"
"G" - Gap Of Welding	Approx. 0.06" Before Welding Recommended Gap
"H" - Min. Flat	Min. Flat = 0.75 X Min. Threaded Wall Thick.



Frequently Used ASME B16.11 Threaded Half Coupling Types

N80, API 5CT, 1/8 inch, Threaded Pipe Couplings

3 Inch, CL3000, ANSI B16.11, Threaded Reducer Couplings

ASTM A105, 2 Inch, Class 6000, FNPT End, Male/ Female Threaded Couplings

ASTM A182 F316, 2000LB, FNPT, Threaded Brass Couplings

ASTM A182 F304, 1/2 Inch, Threaded Joint Couplings

1/4 inch Asme B16.11 Half Coupling Screwed - Class 3000

DN80, ASME B16.11, PN400, Stainless Steel Screwed Half Couplings

API, 9.2 LB, 3.5 Inch, Asme B16.11 Half Coupling



ASTM A105, 4 Inch, ANSI B16.11 Forged Half Couplings

API 6000, NPT Female, Stainless Steel Half Couplings

API 3000, Bs3799, 3000 LB, Screwed Half Couplings

ASME SA105N, Galvanized, B16.11, 9000#, Copper Nickel Screwed Couplings
